Analog Panel Meters

Jewell Instruments offers a wide range of moving iron, moving coil, and stepper motor analog panel meters in A&M, Emico, Jewell, and Modutec Series. Our analog panel meters are designed to measure AC and DC current. Many of these analog panel meter models are CE and UL approved and provided in custom and standard sizes, input ranges, and scales. They are available in different designs, materials of construction, colored dials, and so on, so you can choose them depending on your application requirements.

Analog Panel Meters

Showing all 32 results

Show:
A&M 2.5 Square Ruggedized Series

A&M 2.5 Square Ruggedized Series

Highlights:

Designed and manufactured in conformance with MIL-PRF-10304 (not QPL listed). Ideal for communication or test equipment where severe environmental conditions are encountered. Available size 2.5″.

A&M 4951 Switchboard Ruggedized Series

A&M 4951 Switchboard Ruggedized Series

Highlights:

The A&M Model 4951 power factor meters are designed to meet the requirements of MIL-M-19261 and MIL-M-16034. They are supplied as either self-contained or as a “matched-set” with the external transducer. In the external transducer configuration, the transducer is matched to the meter. Both configurations are sealed watertight.

A&M MR Panel Meter Ruggedized Series

A&M MR Ruggedized Series

Highlights:

Designed and manufactured in conformance with MIL-PRF-10304 (not QPL listed). Ideal for communication or test equipment where severe environmental conditions are encountered. MR34 Long-scale panel meters are ideal for military and commercial applications. Available 1.5″ (MR13), 2.5″ (MR26) and 3.5″ (MR34 & MR35)sizes.

Place holder

Emico Series 12

Highlights:

Edgewise compact indicator is frequently used to indicate go/no-go circuit condition or as a miniature null type zero-center tuning indicator to indicate balance in position. 5% Accuracy meters incorporate a moving magnet mechanism. Available size 1.375″.

Place holder

Emico Series 13

Highlights:

Edgewise meters mount vertically or horizontally with a curved (13) or flat (13F) front. 5% Accuracy meters incorporate a moving magnet mechanism. Available size 2″.

Place holder

Emico Series 802

Highlights:

Series 802 are very small, low-cost, uncalibrated devices for indicating on-off conditions or voltage transition points. They are rugged, dependable, and require less than 2mW to move the flag or pointer. The two types are:

Flag Type (802F)  – A white flag moves from one end of the red & white scale to the other when a predetermined voltage value is exceeded. Provides on-off indication.

Pointer Type (802P) – A pointer moves across the scale to indicate circuit condition. The pointer may be factory set for left, right, or exact center position to indicate zero current. The center point can be specified for a given voltage (±5%) within the range of the device.

Either type can be made to operate with a Zener diode to indicate voltage changes as low as 1 volt.

Jewell surface mounted 50 series analog panel meter

Jewell 50 Series

Highlights:

The Jewell surface mounted 50 series analog panel meter is designed with traditional black case and glass windows. Black phenolic Bakelite covers and cases suited for industrial equipment. Available in both round and square shapes.

Jewell surface and bezel mounted 70 series analog panel meter

Jewell 70 Series

Highlights:

The highly versatile Jewell surface and bezel-mounted 70 series analog panel meter provide maximum flexibility for selecting the size, type of mechanism, and method of mounting. The crystal clear cover is distortion-free and unaffected by aging. The clean, clear appearance of these meters blends with any color scheme.

Place holder

Jewell 80 Series

Highlights:

The Jewell window mount 80 series analog panel meter is designed with a crisp appearance and high visibility. Only the clean lines of the dial face appear on your panel front, providing maximum layout flexibility. This unique space-saving meter saves up to 3 cubic inches behind the panel when compared to “barrel type” meters.

Jewell DS Series Moving Coil Panel Meters

Jewell DE Series – Moving Iron

Highlights:

The moving iron panel meters, DE 48/72/96/144 housed in cases made of molded polycarbonate are suitable for the measurement of AC currents for the frequency range of 15 to 400 Hz and voltages in the frequency range of 15 to 100Hz. Moving iron meters indicate RMS values practically independent of waveform even of high harmonics. An error of indication may occur for extreme waveforms (e.g. phase gating controls) & for frequencies above 100KHz.

These meters offer several advantages in switchboards and generating set panels. A number of meters can be mounted in a panel cutout mosaic mounting. For CT-operated ammeters, dials can be fitted based on CT ratio. Glass and bezel can easily be replaced.

Jewell DG Series - Moving Coil & Rectifier 90° Scale

Jewell DG Series – Moving Coil & Rectifier 90° Scale

Highlights:

The moving coil, rectifier meters, DG 48/72/96/144 are housed in molded polycarbonate cases and are suitable for the measurement of AC currents and voltages. Moving coil rectifier instruments measure average values and are calibrated to indicate RMS values, assuming a sinusoidal waveform for frequencies from 40 to 10000 Hz (AC current for frequency range of 40 to 1000 Hz and AC voltage for frequency range of 40 to 1000 Hz. These instruments offer several advantages in switchboards and generating set panels. A number of meters can be mounted in a panel cut-out (mosaic mounting). Front glass, bezel & dial can easily be replaced

Jewell DGL Series – AC Ammeters/Voltmeters

Jewell DGL Series – AC Ammeters/Voltmeters

Highlights:

The moving coil, rectifier panel meters DGL 48/72/96/144 are housed in polycarbonate cases and are suitable for the measurement of AC currents and voltages. Moving coil rectifier instruments measure average values and are calibrated to indicate RMS values, assuming a sinusoidal waveform for frequencies from 40 to 10000 Hz (AC current – 40 to 1000 Hz and AC Voltage – 40 to 10000 Hz). These instruments offer several advantages in switchboards and generating set panels. A number of meters can be mounted in a panel cutout (mosaic mounting). The front glass, bezel, and dial can be easily replaced.

Jewell DS Series Moving Coil Panel Meters

Jewell DS Series – Moving Coil

Highlights:

The moving coil panel meters DS 48/72/96/144 are housed in cases made of molded polycarbonate and are suitable for the measurement of DC current and voltages. These instruments offer several advantages in switchboards and Generating Set panels. A number of meters can be mounted in a Panel Cut out (Mosaic mounting). The front glass, bezel, and dial can all easily be replaced.

Jewell DSL Series – DC Ammeters/Voltmeters

Jewell DSL Series – DC Ammeters/Voltmeters

Highlights:

The moving coil panel meters, DSL 48/72/96/144 are housed in molded polycarbonate cases are suitable for the measurement of DC currents and voltages. These instruments offer several advantages in switchboards and generating set panels. A number of meters can be mounted in a panel cut out (mosaic mounting). The front glass, bezel, and dial can be easily replaced.

Jewell FM Series – Frequency Meter

Jewell FM Series – Frequency Meter

Highlights:

The pointer type frequency meters, FM 48/72/96/144 are housed in molded polycarbonate cases are suitable for the measurement of frequencies in the range of 45 to 450 Hz. For maximum accuracy, the essential measuring range is obtained by suppressing the unwanted frequency span. These instruments offer several advantages in switchboard and generating set panels. A number of meters can be mounted in a panel cut out (mosaic mounting). The front glass, bezel, and dial can be easily replaced.

Jewell FML Series – Frequency Meters

Highlights:

The pointer type frequency meters, FML 96 and FML 144 housed in molded polycarbonate cases are used for the measurement of frequencies in the range of 45 to 450 Hz. For maximum accuracy, the essential measuring range is obtained by suppressing the unwanted frequency span. These instruments offer several advantages in switchboards and panel cut out. A number of meters can be mounted in a panel cut-out (mosaic mounting). The front glass, bezel, and dial can be easily replaced.

Jewell surface mounted HS series analog panel meter

Jewell HS Series

Highlights:

The Jewell surface mounted HS series analog panel meter is renowned for its resistance to shock, vibration, and moisture. Special parts and fastening reduce the effects of hard usage; a one-piece, steel case provides magnetic and electrostatic shielding; and a convex glass window is hermetically sealed.

Jewell surface mounted MM series analog panel meter

Jewell MM Series

Highlights:

The Jewell surface mounted MM series analog panel meter has the popular medallion shape that revolutionized the meter industry. This space-saving design offers high visibility and rugged durability while blending with today’s high technology applications.

Jewell surface mounted MS Series analog panel meter

Jewell MS Series

Highlights:

The Jewell surface mounted MS Series analog panel meter is designed with a contemporary concave cover to reduce glare and improve readability. Rugged and durable, this aesthetically pleasing rectangular shape interfaces with today’s high technology applications.

Available in sizes 1.5″ up to 3.5″.

Jewell VISTA range of Analog Panel Meters

Jewell VISTA Series

Highlights:

The Jewell VISTA range of analog panel meters offers accurate measurement and indication of most electrical and electronic parameters in the industry as per industrial standard case size. The range offers AC and DC ammeters, voltmeters, and frequency meters utilizing a high torque pivot and jewel
movement. AC moving iron meters also provided 1.5% high accuracy true RMS measurement.

Modutec 0MS & MSQ Series Square Panel Meters

Modutec 0MS & MSQ Series Square Panel Meters

Highlights:

Traditional square meters with the look of the 80s and a low price tag. These have operating zero adjusters and scales printed on translucent plastic, permitting diffused back-lighting using either the external light kit described in “Options” or custom lighting. Installation holes and cutouts are interchangeable with domestic and foreign designs, making product improvement quick and easy.

Place holder

Modutec 2% Panel Meters 2810/CLE8 Series

Highlights:

Features unique case design, enclosed meter movement with the scales located behind an internal housing for greater dust resistance. Scales can be replaced without chance of damage to the movement. Available in sizes 3.5″ and 4.5″.

Modutec E-Series 2? Edgewise Panel Meters

Modutec E-Series 2″ Edgewise Panel Meters

Highlights:

Compact edgewise meter only ½” thick. Self-shielding allows users to stack without magnetic interaction. Lightwell provided for backlighting. Available size 2″.

Modutec MAS Series Rectangular Panel Meters

Modutec MAS Series Rectangular Panel Meters

Highlights:

Attractive contemporary designs with the typical Modutec low aspect ratio. All have operating zero adjusters, and scales printed on translucent plastic, permitting beautifully diffused lighting using either the external light kit described in “options” or a custom light source.

Place holder

Modutec MC1 Series – 250° High Torque Taut-Band Movements Meters

Highlights:

Modutec MC1 movements are technically advanced and offer outstanding features not found in other 250° movements. Their unusually small size and their refined taut-band suspension mean high performance in the area of accuracy, tracking, and repeatability. Their unique design includes shock limiters and vibration stops which combined with optional Fluidyne®
viscous damping gives them exceptional durability and stability in difficult environments.

Mounting is usually by means of three tapped brass standoffs which are swaged to either the front or the back of the movement, as ordered, permitting installation within its 1.25″ O.D.

Dials can be mounted to standoffs on the front of the movement; however, MC1 movements are usually ordered with a universal mounting plate (see drawing) installed. This not only serves as a dial mount but also coordinates with the mounting requirements of many domestic and imported movements. Note that front standoffs are not available when the universal mounting plate is installed.

Standard movements come without front and back dust caps. Either or both will be installed when specified on order.

Modutec MD & ME Series Edgewise Panel Meters

Modutec MD & ME Series Edgewise Panel Meters

Highlights:

Useful space-saving meters in two sizes, interchangeable with many costly d’Arsonval meters or moving magnet meters from other sources. All sizes feature flush-to-panel covers without the bulge that disfigures many edgewise meters. A low-cost option provides internal illumination through a translucent dial – sophisticated lighting unusual in any economy meter, let alone an edgewise type.

Modutec PB Series Surface Mount Panel Meters

Modutec PB Series Surface Mount Panel Meters

Highlights:

The PB Series was designed to meet the expressed need of many customers for meters with a hard-hitting, big-dial area “industrial” look.

PB Series meters are available in many sizes, types, and ranges. Mounting stud configuration complies with ANSI standards: the number of studs is as follows: 1½” meters – 2 studs; 2½” & 3½” meters – 3 studs; 4½” meters – 4 studs. Meters in sizes 1½”, 2½”, and 3½” can be supplied in 4- stud versions at no extra cost.

AC meters in this series are offered in both d’Arsonval (rectifier type) and iron-vane versions. The latter has the virtue of greater standard accuracy and relative insensitivity to input distortion, while the rectifier type is less affected by frequency variations.

Modutec S-Series Surface Mount Panel Meters

Modutec S-Series Surface Mount Panel Meters

Highlights:

The S Series Surface Mount Panel Meters are clean-cut meters with straightforward design and pleasing aspect ratio are leaders of the Modutec line and add distinction to any instrument or control panel. Available in five sizes and a wide variety of types and ranges, they resolve many problems for the equipment designer and are always a solid choice for function and appearance.

AC Meters in this series are available in both moving coil (rectifier type) and iron vane versions. The latter has the virtue of being relatively insensitive to input distortion, while the rectifier type is less affected by frequency variations.

Modutec W-Series Windo-mount™ Panel Meters

Modutec W-Series Windo-mount™ Panel Meters

Highlights:

Windo-mount™ is a sophisticated design that has been found universal acceptance since being introduced many years ago by Modutec. The W series meters are easily installed per applications bulletin AB6-1; when so installed the meter cover is flush with the panel surface, with the dial easily read.

W series meters are available in the same ranges and at the same prices as the S series meters. They offer an excellent functional appearance, plus the looks enhancing edge options available. These meters are very popular for stereo and broadcast equipment.

Modutec World Meter Series – Windo-Mount™ Panel Meters

Modutec World Meter Series – Windo-Mount™ Panel Meters

Highlights:

The World Meters incorporate Modutec’s third-generation taut-band/moving-coil movement – unmatched in any competitive production meter, anywhere – with a space-efficient case and dial configuration that takes about 30% less space than conventional panel meters. The result is a rugged and accurate meter with unique and desirable features, at a very economical price.

Triplett Edgewise Series Panel Meters

Triplett Edgewise Series

Highlights:

.5E Thermoplastic front and steel back. Horizontal mounting. Available size less than .5″.

Triplett Ruggedized Series

Triplett Ruggedized Series

Highlights:

HR Thermoplastic front with steel back shields this meter from magnetic fields. Available size 3. 5″.

Features of Analog Panel Meters Offered by Jewel Instruments

We believe the following features of our devices make them superior to several competitors’ models in the market.

  • Our A&M series analog panel meters feature ruggedized construction and meet the requirements of MIL-M-16034 and MIL-M-19261 standards. The transducers from these series are offered as self-contained or with an external transducer as a matched set depending on your needs. This series also features analog switchboard meters.
  • Emico series analog panel meters are compact-sized and often used as a miniature null-type zero-center tuning indicator or a go/no-go type circuit condition indicator.
  • Jewell series analog panel meters stand out due to their black case and glass windows. These panel meters are suited for industrial applications and are available in square and round shapes.
  • All our analog panel meters are suited for avionics applications, and are offered in custom-designed inputs and scales to meet your application requirements.

Tips to Choose the Right Analog Panel Meters for Your Application

Analog panel meters offer a visual level indication and feature a dial with a moving pointer, scale, or needle, which indicates the corresponding process variable with a change in input value. Generally, these devices accept a single input, but they may accept multiple inputs, too. When they accept multiple inputs, these devices are known as multiple channel analog panel meters. Choosing the right analog panel meter can be difficult owing to the variety in designs. The following pointers will be helpful in this context.

  • Function of the Meter: As said before, analog panel meters can be used to measure different process variables, thus, are named after their function. For instance, the voltmeter is used to measure the voltage of the device, power meter for current, energy meter for energy, and so on. So, first, start the selection by addressing the function of the analog meter.
  • Meter Mechanisms: Analog panel meters follow two types of meter mechanisms – pivot and jewel, as well as taut band. In pivot and jewel analog meters, a pointer and coil is usually suspended to fit into two bearings of jewels. These meters are generally used for measuring AC. On the contrary, a taut band suspends a needle or a pointer between two metal ribbons and helps improve meter sensitivity by reducing friction. Taut band meters are commonly used to measure DC current. Among these, taut band devices are more preferred in environments where they may be exposed to the high level of vibrations and disturbances. Although pivot and jewel analog meters can withstand challenging environments, they are not appropriate for applications that demand a high level of accuracy.
  • Channels: Analog panel meters can be availed with one or multiple channels. The devices with one channel can measure one variable in a single unit, while the devices with multiple channels can measure more variables across units. For instance, some analog meters with one channel can measure DC in volts, while ones with multiple channels can measure AC in millivolts and volts.
  • Face Types: The analog meters can be availed in different face types such as standard, rectangular, round, and edgewise styles. Among these, round meters can be availed in different face diameters, rectangular ones are available in various face diameters and face heights. Standard devices will feature panel cutout diameter or barrel. Edgewise models feature a straight scale, however, round, rectangular, and edgewise models feature curved scales.
  • Displays: All analog panel meters feature pointers, which move mechanically on change in input. These meters may feature illumination, which makes it easy to see them in low light conditions. Height of scale markings must be considered for clear visibility.

At Jewell Instruments, we possess huge market experience spanning over 80 years in industrial and commercial panel meter solutions. Our product lines are conceived to meet the highly precise measurement requirements across each industry we serve. We believe there is no standard solution that works for all clients, which is why we offer a high level of customizability for our products. Our experts work with clients closely to understand their requirements before suggesting solutions. Feel free to get in touch with our team today to discuss your requirements. Our experts will help you find the right solution for your needs.
