Additional Information
| Dimensions | 5.43 × 2.38 × 1.22 in |
|---|---|
| Features | • Wide Operating Temperature Range |
| Applications | • Unmanned Vehicles |
The ECS digital compass represents the state-of-the-art in magnetic compassing. It combines a precision 3-axis solid-state magnetometer and a rugged 2-axis electrolytic tilt sensor to provide accurate heading and tilt measurements over a wide range of environmental conditions. The firmware and signal processing algorithms have been refined and improved over three prior generations of compasses to deliver the ultimate in performance from the available sensor data.
Performance Specifications
Heading Performance
| Accuracy (rms) | ±0.5° | Typical, Tilt <35° Dip <60° |
| Repeatability | ±0.3° | No filter |
| Response Time (msec) | 36 | Minimum, no filter |
| Dip Angle Range | ±80° | |
| Tilt Range | ±42° | |
| Update Rate (measurements per second) | 27.5 |
Pitch and Roll Performance
| Accuracy | ±0.3° | Factory calibrated |
| Repeatability | ±0.20° | No filter |
| Range | ±42° | |
| Settling Time (sec) | 0.5 | No damping |
Electrical
| Supply Voltage (VDD) | 6 - 45Vdc unregulated 5.0Vdc regulated | 4.9Vdc minimum |
| Supply Current | Operating: 25mA sample: 10mA Standby: 2mA | Typical |
Environmental
| Operating Temperature | -40° to 105°C | |
| Storage Temperature | -50° to 150°C | |
| Humidity | 0-90% | Non-condensing |
Mechanical
| Enclosure Material | (ABS) Flame Retardant Plastic UL94 VO Diecast Aluminum Alloy (Type 360.1) |
| PCB Size | 1.6"W x 3.0"L x 0.6"H, H required for tilt sensor |
| PCB Mounting | 4 #4 screws, 1.4″x 2.2″ spacing |
| Weight | Plastic: 3.2oz (90.7g) Aluminum: 7.2oz (204.1g) |
| Connectors | 8 pin, single-row, 0.1″ friction header 6 pin RJ12 modular jack |
Interface
| Signal Type | RS-232 or RS-485 |
| Baud Rate (bps) | 2400, 4800, 9600, 19200, 38400 or 57600 |
| Character Format | 8 data, no parity, 1 stop |
| Input Buffer Size | 110 characters |
| Output Buffer Size | 110 characters |
| Output Format | NMEA 0183 and binary |
| Output Data Rate | 1 to 1650 sentences per minute |
| Operating Modes | Continuous or sample |
| Angle Units | Degrees, mils, radians, 16-bit integer |
*Specifications subject to change without notice on account of continued product development
