Product Tag: dual axis

dual axis

Showing all 26 results

Show:
755 & 756 Miniature Tilt Sensors

755 & 756 Miniature Tilt Sensors

Highlights:

755- and 756-Series Miniature Tilt Sensors contain one or two of our electrolytic tilt transducers in a solid stainless steel or aluminum housing, with holes for vertical or horizontal mounting. These are the same high-precision sensors that we use in our 500– and 700-Series tiltmeters. Several of the models are available in vacuum-compatible versions designed for minimal outgassing under high-vacuum conditions. Two options are available, the high-gain 755-Series and mid-range 756-Series. Typical applications for these compact modules include X-ray mirrors, telescope mounts, wind tunnel models, and medical devices. The sensors may be operated at a distance (cable length) up to 100m from their Jewell Instruments signal conditioner.

AMA Analog MEMS Accelerometer Series

AMA Analog MEMS Accelerometer Series

Highlights:

Jewell Instruments AMA Series Accelerometers are an excellent choice for cost to performance trade off. The AMA is based on silicon micro-machined MEMS Capacitive Accelerometer technology and designed for low power and high stability.





AMH Analog MEMS Inclinometer Series

AMH Analog MEMS Inclinometer Series

Highlights:

The AMH Series is a single or dual axis, high precision MEMS inclinometer. Standard units come with 0-5V, 0.5-4.5V or 4- 20mA output options. All AMH series inclinometers are rated IP67 for waterproofing up to 1m. Custom ranges and output types are also available on request



AMI Analog MEMS Inclinometer Series

AMI Analog MEMS Inclinometer Series

Highlights:

The AMI Series is a single or dual axis, high precision MEMS inclinometer with built-in thermal compensation. Standard units come with 0-5V, 0.5-4.5V or 4-20mA output options. All AMI series inclinometers are rated IP67 for waterproofing up to 1m. Custom ranges and output types are also available on request



AML Analog MEMS Inclinometer Series

AML Analog MEMS Inclinometer Series

Highlights:

The Jewell Instruments model AML is a low cost analog MEMS inclinometer for industrial applications. Standard units are available with 0-5V, 0.5-4.5V and 4-20mA output options. All AML series inclinometers are rated IP67 waterproof up to 1m. Custom ranges and output types are also available on request.

DMH Digital MEMS Inclinometer Series

Highlights:

The Jewell Instruments model DMH is a high precision MEMS inclinometer. Units are available with RS-232, RS-422, RS-485 and UART TTL options. All DMH series inclinometers are rated IP67 for waterproofing up to 1m. Custom ranges and output types are also available on request.

DML Digital MEMS Inclinometer

DML Digital MEMS Inclinometer

Highlights:

The Jewell Instruments model DML is a low cost digital MEMS inclinometer for industrial applications. Units are available with RS-232, RS-485 and UART TTL output options. All DML series inclinometers are rated IP67 for waterproofing up to 1m. Custom ranges and output types are also available on request.

DMS Digital MEMS Inclinometer

DMS Digital MEMS Inclinometer

Highlights:

The model DMS is a mid-level performance digital MEMS inclinometer for industrial applications. Standard units are available in RS-232, RS-485 and UART TTL interface options. All DMS series inclinometers are rated IP67 for waterproofing up to 1m. Custom ranges and output types are also available on request.

DXI-100/200 Digital Inclinometer

DXI-100/200 Digital Inclinometer

Highlights:

The Jewell DXI-100/200 Series single or dual digital inclinometer takes Jewell’s highly accurate analog closed-loop sensor technology to the next level. The DXI-100/200 is available with either RS-422 or RS-485 (Standard) digital interfaces. With a variety of options, including metric mounting threads, a flanged base, and CENELEC/AREMA certified, this product is easily customized to suit your specific application.

CENELEC-CECC-Logo

arema_web







eDXI-100/200 Single or Dual Axis Digital Inclinometer

eDXI-100/200 Single or Dual Axis Digital Inclinometer

Highlights:

The Jewell eDXI-100/200 Series is a single or dual digital inclinometer with the convenience of Ethernet output. With its power over ethernet capability, no power source is needed. Simply plug it in to your computer.





JDI-100/200 Digital MEMS Inclinometer Series

JDI-100/200 Digital MEMS Inclinometer Series

Highlights:

The JDI-100/200 series is a digitally temperature compensated inclinometer available in single and dual-axis configurations. The robust and rugged design is great for industrial use, yet includes the low-cost MEMS technology. These units are available with DB9, Pigtail, Deutsch, Double Deutsch, 6-Pin Circular (C06), or M12 connectors for maximum versatility.RoHs_logo





JMA-100/200/300 Analog MEMS Accelerometer Series

JMA-100/200/300 Analog MEMS Accelerometer Series

Highlights:

The JMA-100/200/300 series is available in single (JMA-100), dual (JMA-200), and triple (JMA-300) axis configurations. This presents a robust and rugged design for industrial use, but with the benefit of low-cost MEMS technology.
RoHs_logo

JMI-100/200 Analog MEMS Inclinometer Series

JMI-100/200 Analog MEMS Inclinometer Series

Highlights:

The JMI-100/200 series is a robust and rugged MEMS inclinometer available in single and dual-axis configurations. The low-cost MEMS technology is great for industrial use. These units are available in single-axis or dual-axis, and we also offer three output options: 0-5VDC (S series), 4-20mA (L series), and ±5VDC (D Series).

RoHs_logo

LCF-196 Dual-Axis Analog Inclinometer

LCF-196 Dual-Axis Analog Inclinometer

Highlights:

The Jewell LCF 2000 Series dual axis inclinometer is a rugged, high accuracy version of the LCF Series. It is available with a wide range of options including single ended input power, internal temperature sensor and 4-20mA.





LCF-2000 Dual-Axis Analog Inclinometer

LCF-2000 Dual-Axis Analog Inclinometer

Highlights:

The Jewell LCF 2000 Series dual axis inclinometer is a rugged, high accuracy version of the LCF Series. It is available with a wide range of options including single ended input power, internal temperature sensor and 4-20mA.





LCF-2530 Series Linear Accelerometer

LCF-2530 Series Linear Accelerometer

Highlights:

The Jewell LCF-2530 Series is a dual axis version of the rugged, high accuracy LCF Series. The design of the LCF-2530 was optimized to provide the high suspension, servo technology in a small and convenient package for applications requiring a a compact dual axis solution.

Model 750-200 Tiltmeter Series

Model 750-200 Tiltmeter Series

Highlights:

The 750-200 tiltmeter series is a rugged, shock and vibration resistant, dual-axis tilt sensor designed for geotechnical applications. It is available in a small, convenient package and offers the options of 0-5Vdc or 4-20mA output signals.





Model 801 “Tuff Tilt” Tiltmeter SeriesModel C904 Clinometer Pak 420

Model 801 “Tuff Tilt” Tiltmeter Series

Highlights:

The Model 801 “Tuff Tilt” Tiltmeter series combines high precision and durability in an economical instrument package. Using an absolute gravity referenced electrolytic sensor, the 801 series delivers superior measurement accuracy with virtually no long-term drift. Units are available in a variety of configurations including single axis (uniaxial), or dual axis (biaxial), analog, digital, or 4-20mA outputs.

All units are rated IP65 waterproof for advanced protection from the elements.





Model 802 Deep Water Submersible Tiltmeter Series

Highlights:

The Model 802 DeepWater Series is the fully submersible cousin of our Model 801 Tuff Tilt Series. Performance features are the same, but the DeepWater housing is machined from a solid piece of 316 stainless steel and incorporates a high-pressure neoprene connector. The pressure rating is 250 bars (2500 meters depth). Higher-pressure versions may be special ordered. Temperature rating is governed by the neoprene connector. Wider temperature range is available with other connector types. Units are available in a variety of configurations including single axis (uniaxial), or dual-axis (biaxial), analog, digital, or 4-20mA outputs.



Model 850 MEMS Tuff Tilt Series

Model 850 MEMS Tuff Tilt Series

Highlights:

This geotechnical MEMS tiltmeter is available in uniaxial and biaxial configurations. It presents a robust and rugged design for outdoor geotechnical use, but with the benefit of low-cost MEMS technology and ±5VDC, 0-5 VDC, or 4-20 mA output signals. It is an effective tilt sensing solution for platform leveling/positioning, structural monitoring, construction monitoring, industrial machinery positioning, radial gate measurement & control.

ROHs



Model 875 Mini Tuff Tilt

Model 875 Mini Tuff Tilt

Highlights:

The model 875 Mini “Tuff Tilt” Tiltmeter combines high precision and durability in a miniaturized and economical instrument package. Using MEMS technology, the 875 delivers superior measurement accuracy with virtually no long-term drift and a resolution of 0.05°. Output options include 0.5-4.5Vdc, 4-20mA and digital RS-485. All units are rated IP67 waterproof for advanced protection from the elements. Use the 875 Mini “Tuff Tilt” for structural monitoring, angle measurement, and control, platform leveling, testing and research, OEM, and more.

RoHs

Model 900 Biaxial Clinometer

Highlights:

The dual-axis Model 900 is an inexpensive, gravity-referenced clinometer with analog voltage output and compact dimensions. Sold without a housing, its small size and performance make it an excellent choice for many OEM, test, and measurement applications. It is available in high-gain, standard, and wide-angle versions, each with a different angular range. Model 900 accepts a wide input voltage range and provides high-level single-ended outputs that are easily measured with any voltmeter or digital recording system. Viscous damping and temperature measurement are available as options.





Model 901 & 902 Clinometer

Model 901 & 902 Clinometer

Highlights:

Model 901 (horizontal) and 902 (vertical) Uniaxial & Biaxial Clinometers accurately measure an angular position with the same performance as Model 900, but in a slim design for use where space is limited. High-gain, standard, and wide-angle versions are available, each with a different angular range. A901 and A902 (biaxial) use high-level voltage outputs to allow signals to be delivered over long cables. C901 and C902 – also referred to as ‘Tulip’ (uniaxial) are loop-powered, so measurements can be made using an economical 2-wire pair. These conveniently sized, low-cost units fit neatly into underwater pressure housings, well logging tools, drilling equipment, and many other devices.





Model 906 Little Dipper In-Place Inclinometer

Model 906 Little Dipper In-Place Inclinometer

Highlights:

Little Dipper is an in-place inclinometer system for monitoring slopes, embankments, deep excavations, tunnels, tank foundations, retaining walls, and other types of ground movement. Installed as a string of vertical or horizontal sensors inside inclinometer casing, or by direct burial, this instrument provides a continuous record of ground displacement. Fiberglass rods connect the sensors inside the casing, and fins or universal pivots couple the sensors to the casing walls. Little Dipper’s on-board electronics accept a wide input voltage range and drive long cables without signal loss. The waterproof and non-corrodible ABS sensor housing also makes the Little Dipper a popular tool for underwater tilt measurements in shallow marine applications. Select analog voltage output (biaxial) or 4-20 mA output (uniaxial only).

Model 750-200 Tiltmeter Series

Model D750-100/200 Tiltmeter Series

Highlights:

The D750-100/200 tiltmeter series is the digital version of the Black Diamond Tiltmeter sensor line for geotechnical measurement. It includes a 0.001° and industry standard RS-485 or RS-422 digital output signals.





Model MD908 ‘IRIS’ Tilt Switch

Model MD908 ‘IRIS’ Tilt Switch

Highlights:

The IRIS Tilt Switch and Controller is a powerful tilt controller device that combines a digital, dual-axis clinometer and advanced firmware features in one compact unit. This remarkable instrument enables you to measure and respond to rotational movements in any direction concerning the unchanging gravity vector. Units ship standard with a 24-inch hook-up cable. IRIS is an ideal choice for OEM applications, where it can be used to maintain platform levelness, avoid tip-over conditions, prevent out-of-range movement, and perform other control functions.
